NORWEGIAN SUBSEA eMRU
KEY FEATURES
- Easy to install due to the passive Power Over Ethernet (PoE) interface
- Fast installation and low cabling cost as RJ45 ethernet connector and cat5e cable is used to connect to MRU.
- Dust and splash proof.
- Suitable for mounting indoors or inside a control box.
- Available in 3 versions: 3000, 6000 and 9000 for different accuracy requirements and budgets.
- Available in an inclinometer version without Heave/Surge/Sway outputs
eMRU Specification
| Roll & Pitch | 0.05° (3000 series) - 0.02° (6000 series) - 0.01° (9000 series) - RMS (dynamic) |
|---|---|
| Heave (real-time) | 5.0 cm or 5.0 % - Whichever is greater for 0 to 25 s periods, valid for irregular motions in real sea conditions. |
| Ports | Ethernet with Passive PoE |
| Communication | TCP, UDP, Modbus TCP, ethernet/IP |
| Protocols | NMEA, ASCII, Binary TSS1, MDL, Atlas, Simrad EM 3000, NORSUB, Custom, etc. ++. See protocol list. |
| Connector | RJ45 |
| Output frequency | 0-100 Hz |
| Casing material | Aluminium |
| Weight | 0.55 kg |
| Dimensions | 120 x 57 x 53 mm |
| Depth rating | IP20 |
